Product Description
Includes specialized trocars and targeting arms for antegrade, retrograde, and reconstruction techniques, reducing the need for multiple independent sets.
The carbon-fiber targeting system allows for clear, unobstructed lateral views during the critical placement of reconstruction screws into the femoral neck.
Features premium flexible reamer shafts and heads that provide smooth canal preparation even in the dense cortical bone of the femoral diaphysis.
The instrument layout is logically sequenced to follow the surgical workflow, facilitating faster instrument identification and tray turnover for hospital staff.
The set is indicated for all standard femoral shaft fixations, providing the necessary tools for both proximal (hip-down) and distal (knee-up) insertion approaches.
Equipped with specialized "Recon" targeting arms specifically indicated for complex trauma cases where simultaneous stabilization of the femoral neck and shaft is required.
Indicated for fractures at the extreme ends of the femoral bone, where the set’s multi-planar locking jigs provide the accuracy needed for stable metaphyseal anchorage.
Contains the heavy-duty reamers and extraction tools necessary for revision procedures, allowing for the removal of failed hardware and the realignment of the femoral axis.
| Product name | Femoral Intramedullary Nail Instrument Set |
| Material | Stainless Steel |
| Diameter | / |
| Length | / |
| Application | / |
| Certificate | CE Certificate |
| Brand | TOOLMED |
| MOQ | 1 Pcs |
| OEM | Avaliable |
| Package | PE Inner Bag+Carton |
| Payment Method | T/T，Bank transfer, Western Union |
| Delivery Time | 5-7 days |
| Shipping | DHL EMS UPS TNT FEDEX |
The Femoral Intramedullary Nail Instrument Set is a high-precision, comprehensive system of surgical tools specifically designed for the internal fixation of femoral fractures. This set provides the critical hardware needed to prepare the medullary canal of the femur and accurately position titanium implants. It includes specialized entry tools, flexible reaming systems, and multi-functional targeting jigs. These jigs are essential for the guided placement of locking screws in both the proximal and distal regions of the femur. Manufactured from a combination of high-strength medical alloys and radiolucent materials, the set is designed to offer maximum durability and precision while facilitating clear visualization under intraoperative fluoroscopy.
This instrument set is applied in orthopedic trauma surgery for the management of fractures of the femoral diaphysis, subtrochanteric region, and supracondylar area. Because of its multi-functional design, it is applied in antegrade procedures (through the greater trochanter or piriformis fossa) and retrograde procedures (through the knee). It is particularly vital in "reconstruction mode," where it is applied to stabilize simultaneous femoral neck and shaft fractures. Additionally, the set is used for pathological fractures and in revision surgeries to remove old nails and re-ream the canal for new fixation. Its wide array of components makes it the primary tool for treating high-energy femoral injuries in trauma centers.
The primary advantage of the TOOLMED Femoral Instrument Set is its exceptional surgical flexibility, allowing surgeons to switch between different nailing techniques using a single, unified system. The inclusion of radiolucent carbon-fiber targeting arms provides a significant advantage by allowing for clear X-ray imaging of the fracture reduction without the jig obscuring the view. Our flexible reamers are designed with an optimized flute geometry to ensure efficient bone removal and reduced intramedullary pressure. Furthermore, the high-grade stainless steel construction of the drivers and inserters ensures high torque resistance and long-term reliability. The modular tray design also improves efficiency by simplifying the sterilization and preparation process for the surgical team.
Biomechanically, the instrument set ensures that the titanium nail is implanted in the most stable mechanical position possible. The reaming tools are calibrated to create a precise canal diameter that ensures optimal load-sharing between the nail and the femoral cortex. The targeting jigs are biomechanically aligned to compensate for the natural curvature of the femur, ensuring that locking screws are placed in the center of the nail's holes to prevent hardware "toggle." By facilitating the creation of a rigid "fixed-angle" construct in the reconstruction mode, these instruments provide the stability needed for the femoral neck to resist high shear forces during early patient mobilization.
The surgical technique involves establishing a precise entry point using the set's cannulated awl. A guide wire is passed down the femur, and the flexible reamers are used sequentially to prepare the canal. The titanium nail is then mounted to the inserter handle and driven into the bone. Depending on the technique (antegrade, retrograde, or recon), the corresponding targeting jig is attached to the handle. Using the jig's sleeves as guides, holes are drilled for the locking screws. The depth gauge is used to select the correct screw length, and the screwdriver secures the screws through the nail. The technique concludes with the use of the set's dedicated drivers to tighten the end cap, completing the internal fixation.
Postoperative care for the instrument set involves a strict decontamination process. Following surgery, all instruments must be disassembled and cleaned to remove all traces of biological material. Specialized cleaning brushes must be used for all cannulated tools. The components should be processed in an ultrasonic cleaner and then sterilized using a standard steam autoclave at 134°C. For the facility, regular maintenance includes checking the targeting jigs for calibration and ensuring all reamer heads remain sharp. Proper care ensures the longevity of the set and prevents surgical complications related to worn or dull instruments, maintaining a high standard of patient safety in future femoral procedures.
The TOOLMED Femoral Intramedullary Nail Instrument Set provides the ultimate combination of precision, versatility, and durability for femoral trauma surgery. By supporting antegrade, retrograde, and reconstruction approaches within a single system, it ensures that surgeons have the right tools for any femoral fracture pattern, leading to improved surgical efficiency and better patient outcomes.
Yes, the TOOLMED set is a "multi-functional" system that contains the specialized targeting arms and inserters required for both hip-down (antegrade) and knee-up (retrograde) surgical approaches.
Standard metal jigs can block the surgeon's view on X-ray. Our radiolucent carbon-fiber jigs are "invisible" under fluoroscopy, allowing for a clear view of the bone and nail holes for highly accurate screw placement.
Our flexible reamer shafts are designed with a universal AO-type connection, making them compatible with most standard orthopedic power systems found in modern operating rooms.
Yes, the set includes the specialized "Reconstruction" targeting arm and sleeves specifically designed to guide the placement of 6.5mm screws into the femoral neck when treating ipsilateral fractures.
We recommend a "bench test" before every surgery by passing a drill through the jig sleeves while the nail is attached. If there is no resistance, the jig is perfectly aligned and ready for use.
